BTM Tog-L-Loc system

Position：首頁 > BTM Tog-L-Loc system

Product highlights

Clinch process is to produce permanent deformation or locking of the metal to be connected by means of stamping equipment, punch and die, there are four kinds of molds: Tog-L-Loc, Lance-N-Loc, Oval-Loc and V-Loc

Vertical BTM Clinch Machine

Description

The body adopts the stationary structure, the pressurization system adopts the pneumatic-hydraulic booster cylinder, the rigidity of the body is good, with 8 tons, 15 tons two models

view

Hand held clinch gun

Description

The structure is simple and portable, and the output pressure is 3 tons

view

Clinch Tooling

Description

The rivetless riveting system is to form plastic deformation of the connected metal by rivet head and rivet seat under pressure to achieve the purpose of connection, which can be divided into four types of riveted joints: Tog-L-Loc, Lance-Loc, Oval-Loc, V-Lock

view

CN +86 020-87813325

BTM Tog-L-Loc system

Product highlights

Vertical BTM Clinch Machine

Description

The body adopts the stationary structure, the pressurization system adopts the pneumatic-hydraulic booster cylinder, the rigidity of the body is good, with 8 tons, 15 tons two models

8T Clinch Machine

ZMY-008-1T1A00

1. Using a special rivet head and rivet seat, the two types of plastic deformable metals are extruded into the rivet seat by pressure to achieve a permanent bond 2. Both the rivet head and rivet seat are consumables

15T Clinch Machine

ZMY-015-001-18007

1. Using a special rivet head and rivet seat, the two types of plastic deformable metals are extruded into the rivet seat by pressure to achieve a permanent bond 2. Both the rivet head and rivet seat are consumables

Hand held clinch gun

Description

The structure is simple and portable, and the output pressure is 3 tons

Adaptable Bayonet Unit

Air/Oil Crocodile Unit

EN-12-584

Bayonet Unit

Adopt booster mechanism to output high pressure oil to the handheld riveter, the pressure can reach 5 tons

Lit-L-Loc Units

ZMY-005-007-13001

Adopt booster mechanism to output high pressure oil to the handheld riveter, the pressure can reach 5 tons

UniClinch Unit

Adopt booster mechanism to output high pressure oil to the handheld riveter, the pressure can reach 5 tons

Clinch Tooling

Description

The rivetless riveting system is to form plastic deformation of the connected metal by rivet head and rivet seat under pressure to achieve the purpose of connection, which can be divided into four types of riveted joints: Tog-L-Loc, Lance-Loc, Oval-Loc, V-Lock

Lance-N-Loc

Lance-N-Loc

Oval-Loc

Oval-Loc

V-Loc

V-Loc

Tog-L-Loc

Tog-L-Loc

Tog-L-Loc has the widest range of sizes for a wide range of applications
